  Incinerator Model YD-100 is a middle scale incineration machine for many different usage: for a middle hospital sickbed below 500 units, for all small or big size family pets (like Alaskan Malamute Dog), for community Municipal Solid Waste Incineration, etc. The primary combustion chamber volume is 1200Liters (1.2m3) and use diesel oil or natural gas fuel burner original from Italy.
All our incinerator use stainless steel chimney, not steel.All our incinerator have two combustion chamber at least, not single chamber. All fuel burner from Italy made with famous brand, best quality.
300kgs per hour burning rate incinerator is well liked by market because this model can be medical waste incineration equipment for big hospital and also very good for other solid waste treatment with lowest cost, even if big size animals also can be feed into the combustion chamber. The primary combustion chamber volume is 2.4m3, big enough for common size animals. For shipping transport, YD-300 can be loaded into 40’feet full high container.
Big size combustion chamber up to 4.0m3 and Internal Dimensions is 257 x 147 x 108cm with feeding door opening 108 x 128cm. This model can be a small waste incineration factory with little amount of budget funds. If end customer use this for farm to burn animals like cow, horse or camel, contact with us now.

THIRD SCHEDULE

(Regulations 26, 47)



STANDARD FOR TREATMENT AND DISPOSAL OF WASTES



A. Classification of Incinerators



Class 1: Industrial Plants Burning Waste as an Additional/Alternative Fuel

Incinerators in which the waste serves as the fuel or supplementary fuel in an industrial process (e.g. the use of cement kilns or any other industrial boilers or furnaces for the disposal of noxious or hazardous materials).




Class 2 Industrial Incinerators

Class 2A: Commercial

Incinerators for the disposal of waste that contains hazardous, potential hazardous and bio-medical waste where the operator exceeds 100 Kg/day.



Class 2B: Small Scale Incinerators for Private Use

Incinerators for the disposal of hazardous, potential hazardous and bio-medical waste where the operator does not exceed 100 kg/ day.


Class 3: General waste Incinerators

Incinerators for general waste that is non toxic, non hazardous, non medical or does not contain organic halogens, i.e., selected customs, police, contraband goods, offices waste, commercial waste and industrial wastes) where the operator does not exceed 1 ton/ day.





STANDARDS, GUIDELINES, CRITERIA, PROCEDURE FOR INSTALLING/OPERATING INCINERATORS


No. Parameter Standards, Guideline, Criteria and Procedure


1

Basic Plant Design
An approved plant must have four distinct sections that demonstrate three principles of Turbulence, Residence Time and Temperature are inbuilt in the plant design .The regulated sections may include but not limited to:



Overall plant layout.

Feed chamber/ charging ---build by local customer

Primary Combustion Chamber. --yes

Secondary Combustion Chamber. --yes

Particulate Scrubbers---- filter brick chamber included

Acid Gas Scrubbers---none

The stack/ chimney. --yes
2 Feeding And Charging Controlled hygienic, mechanical or automatic feeding methods have to be used which will not influence the air temperature in the primary and secondary chambers of the incinerator negatively.



No waste is to be fed into the incinerator:



Until the minimum temperatures have been reached.—manual feeding
If the minimum combustion temperatures are not maintained. --yes
Whenever the previous charge has not been completely combusted in the case of batch feeding. --yes



Until such time as the addition of more waste will not cause the design parameters of the incinerator to be exceeded. --yes


3 Primary Combustion Chamber The primary combustion chamber must:



Be accepted as the primary combustion zone. --yes
Be equipped with a burner/s burning gas/fuel or low sulphur liquid fuels. Other combustion methods will be judged on merits. --yes



Ensure primary air supply is controlled efficiently--yes
Ensure minimum exit temperature is not less than 850oC—800-1000 oC


4 Secondary Combustion Chamber (Afterburner). The secondary combustion chamber must:



Be accepted as secondary combustion zone. --yes
Be fitted with secondary burner/s burning gas or low sulphur liquid fuel or any suitable fuel. --yes



Ensure secondary air supply is controlled efficiently. --yes
Ensure flame contact with all gases is achieved. --yes
Ensure residence time is not less than two (2) seconds. --yes
Ensure the gas temperature as measured against the inside wall in the secondary chamber & not in the flame zone, is not less than 1100oC.—1000-1200 oC



Ensure the oxygen content of the emitted gases is not less than 11%.--yes
Ensure both primary and the combustion temperatures are maintained until all waste has been completely combusted--yes


5 Particulate Removers A mechanical particulate collector must be incorporated after secondary combustion chamber for removal of particulate pollutants entrained in the flue gas stream. The particulate collectors may include any of the following or a combination thereof:



Cyclone separator

Electrostatic precipitators

Fabric filters--- filter brick
6 Chimney / Stack

The chimney should have a minimum height of 10 meters above ground level and clear the highest point of the building by not less than 3 meters for all roofs. The topography and height of adjacent buildings within 50 meters radius should be taken into account.—6 meter already, can plus 4 meters, free cost



If possible the chimney should be visible to the operator from the feeding area.—according to local site
The addition of dilution air after combustion in order to achieve the requirement of these guidelines is unacceptable.--yes



The minimum exit velocity should be 10 m/s and at least twice the surrounding wind speed (Efflux velocity = wind speed x 2) whichever is higher to ensure no down washing of exiting gases. .--yes





Point for the measurement of emissions shall be provided. .--yes




7 Instrumentation Instrument for determining the inside wall temperature and not burner flame temperature must be provided for both primary and secondary chambers.--yes



An audible and visible alarm must be installed to warn the operator when the secondary temperature drops to below the required temperature.

--none

In addition to the above the following instruments may also be required.

A carbon monoxide and/or oxygen meter/recorder

A smoke density meter/recorder

A gas flow meter/recorder

A solid particulate meter/recorder

Any other instrument or measurement that may be considered necessary--none




8 Location / Siting

Must be sited in accordance with the relevant local municipal authority planning scheme, the topography of the area and be compatible with premises in the neighborhood,



Must be housed in a suitably ventilated room.

---according to local site


9 Emission Limits

Combustion efficiency:





Combustion efficiency (CE) shall be at least 99.00%

The Combustion efficiency is computed as follows;



C.E= % CO2 x 100

% CO2 + CO



The temperature of the primary chamber shall be 800 ± 50o C



The secondary chamber gas residence time shall be at least 1 (one) second at 1050 ± 50o C, with 3% Oxygen in the stack gas.





4 Opacity of the smoke must not exceed 20% Viewed from 50 meters with naked eyes

All the emission to the air other than steam or water vapour must be odourless and free from mist, fume and droplets.



The Authority may require that the certificate holder have tests carried out by an accredited institution to determine stack and/or ground level concentrations of the following substances.



Cadmium and compounds as Cd

Mercury Hg

Thallium Tl



Chromium Cr

Beryllium Be

Arsenic As

Antimony Sb

Barium Ba

Lead Pb

Silver Ag

Cobalt Co

Copper Cu

Manganese Mn

Tin Sn

Vanadium V

Nickel Ni

Hydrochloric HCL

Hydrofluoric acid HF

Sulphur dioxide S02



A 99.99% destruction and removal efficiency (DRE) for each principal organic hazardous constituent (POHC) in the waste feed where:



DRE = [(Win - Wout)/Win]*100

Where: Win = mass feed rate of the POHC in the waste stream fed to incinerator, and

Wout = mass emission rate of POHC in the stack prior to the release to the atmosphere.



The average dioxin and furan concentration in the emissions should not exceed 80ng/m3 total dioxins and furans if measured for a period of 6 to 16 hours.



Note:

All pollutant concentrations must be expressed at Oo C and 1.013 x 10 5 N/m2, dry gas and 11% oxygen correction.



Oxygen correction is computed as:



Es = 21 – Os x EM

21 - OM


Where: Es = Calculated emission concentration at the standard percentage oxygen concentration

EM = Measured emission concentration

Os = Standard oxygen concentration

OM = measured oxygen concentration


10 Operation

Materials destined for incineration should be of known origin and composition and must be only incinerated in a furnace that is registered for the particular type of waste.



A record must be kept of the quantity, type and origin of the waste to be incinerated.
The incinerator must be preheated to working temperature before charging any waste.
The incinerator must not be overcharged.
The incinerator must be in good working order at all times and must not be used if any component fails. Any malfunction should be recorded in a log book and reported to the relevant authority.



The incinerator operator and all relevant staff must be trained to the satisfaction of the relevant control authority. ---according to local site




11 Housekeeping The site where the incinerator is built must:



Have running water.
Have a solid floor.
Have lighting if 24hrs operation
Have fly ash containerization and storage before disposal.

---according to local site


12 Health & Safety (Protective Gear)

Staff handling waste must be well trained on safe handling of hazardous wastes
Staff must be provided with appropriate protective gear such as, gas mask, aprons, gumboots, helmets, gloves, goggles.



Caution and Warning signs must be provided.
Fire fighting equipment must be provided
There should be no smoking or eating on the site.

---according to local site





　
