SPECIFICATIONS: Incinerator

Purpose: Top Loader incinerator of general, medical and dry waste to comply with the requirements of the Air Quality Act, 2004 (Act No 39 of 2004)

1	Design standard	Retort type, multiple
2	Description of chimney	Top mounted, self supporting, unlined
3	Stack height from base	At least 11 meter (depends on height above sea level)
4	Incineration performance Capacity	750 kg/hour
5	Temperature Primary	Minimum 850 degree Celsius
6	Temperature Secondary	Minimum 1000 degree Celsius
7	Dimensions (minimum)(cm) Length Width Height	210 180 210
8	Loading door opening (m)	200
9	Description of grate/hearth	Full
10	Primary chamber volume (minimum)	1.05 cubic meters
11	Tools included	Poker, hoe, rake
12	Materials of construction (minimum) Case Bracing Hearth 　　　 Ashing door Loading door 　　　　 Refractory walls and roof	5 mm mild steel Heavy angle and channel 1550 degree Celsius castable general purpose high strength, high abrasion resistant monolithic refract concrete High grade cast iron 5 mm mild steel lined with 1550 degree Celsius castable general prupose high strength, high abrasion resistant monolithic refractory concrete 1550 degree Celsius castable general prupose high strength, high abrasion resistant monolithic refractory concrete
13	Refractory concrete – alumina content	At least 48%
14	Refractory thickness	Not thinner than 102 mm but in primary chamber minimum 152 mm and 125 mm thick
15	Insulation to walls	1000 degree castable insulation
16	Chimney stack Chimney Diameter of chimney at top Weight of stack	5 mm mild steel Minimum 430 mm Approx 500 kg
17	Controls Barometer damper Door operated draught limiter Air supply: built in forced draught heated air primary and secondary (intensifier) Control panel includes circuit breakers, main switch, timer, 2 set point pyrometer and one set point pyrometer, thermometer
18	Electrical supply required	3-phase
19	Auxiliary fuel	Diesel or paraffin
20	Primary burner
21	Secondary (after) burner
22	Type of burners	Automatic pressure jet
23	Output Primary	Approx 600 000 kJ/hour
24	Output Secondary	Approx 750 000kJ/hour
25	Emission control Heated refractory screen Low velocity grit arrester screen	Built in
26	Paint case	400 degree Celsius resisting black
27	Paint stack	400 degree Celsius resisting aluminium
28	Temperature of case	Not exceeding 90 degree Celsius
29	Intensifier
30	Automatic fan control
31	GRE factor	1.5
32	Noise (primary) Noise (secondary)	72 dBA
33	Transport and rigging of plant including crane hire	76 dBA
34	Certificate of analysis as per Annexure 1
35	Commissioning of incinerator
36	Guarantee	3 years
37	Training of operators
38	Availability of local distributor for spare sparts

ANNEXURE 1

Common Name	Chemical symbol	Compliance: mg/Nm³ under normal conditions of 10% O₂, 273 Kelvin and 101.3 kPa
Particulate matter		10
Carbon monoxide	CO	50
Sulphur dioxide	SO₂	50
Oxides of nitrogen	NO_x expressed as NO₂	200
Hydrogen chloride	HCl	10
Hydrogen fluoride	HF	1
Sum of Lead, arsenic, antimony, chromium, cobalt, copper, manganese, nickel, vanadium	Pb⁺, As⁺, Sb⁺, Cr⁺, Co⁺, Cu⁺, Mn⁺, Ni⁺, V	0.5
Mercury	Hg	0.05
Cadmium Thallium	Cd⁺Ti	0.05
Total organic compounds	TOC	10
Ammonia	NH₃	10
		Compliance: ng I TEQ/Nm³ under normal conditions of 10% O₂, 273 Kelvin and 101.3 kPa
Dioxins and furans	PCDD/PCDF	0.1
