Model

YZ-20

Capacity(Kgs/Hour)

About 20

Applicable Sick Bed(Beds)

200

Voltage(V)

220

Power(Kw)

0.77

Oil

Diesel Oil(light Diesel oil beneath 10#)

Burner

Baltur, Italy Original

Feed Mode

Manual

Prohibit Waste

Incombustible and explosive materials not allowed in

Gross Weight(Kgs)

1700

Package Material

Wooden Carton

Package Size(mm)

1700(L) x 1580(W) x 2250(H)

Chimney

Length: 6.4M, Diameter:250mm

Fuel consumption:

Primary Burner: 2.7-6.3Kgs/Hour

Secondary Burner: 2.7-6.3Kgs/Hour

Solid combustion chamber((Primary& Secondary, M3)

0.22

Gas Combustion Chamber(M3)

0.20

Solid Chamber temperature(⁰C)

800-1000

Gas Chamber temperature(⁰C)

1000-1200

Burning efficiency

＞98%
