Equipment Technical Specifications

Model

SYC-50

Feed Chamber

Burning Rate

35kgs per hour

can be 50kgs per hour

Voltage

380V

Power

3.70Kw

Fuel

Natural Gas or Diesel oil or LPG gas

Burner

China Burner

Feed Mode

Manual

Post Combustion Chamber

350Liters

Door Opening

60 x 60cm

Chimney

4.5M

Gross Weight

4000kgs

Chamber Material

Firebrick, Refractory Concrete

Operation Technical Specifications

Solid Chamber temperature

800 ⁰C -1000 ⁰C

Gas Chamber temperature

1000 ⁰C -1200 ⁰C

Chamber Anti-Rate

1350⁰C

Residency time

2.0 Sec.

Burning efficiency

＞95%
