Equipment Technical Specifications

Model

YD-100

Feed Capacity

200-400 kgs per feed

Burning Rate

100 kgs per hour

Burning Time per Feed

2-4 hours

Voltage

380V

Power

0.9Kw

Fuel

Natural Gas or Diesel oil

Burner

Italy Burner

Feed Mode

Manual

Fuel consumption (Oil)

12.0-25.0 Kgs/Hour

Fuel consumption (Gas)

12.0-30.0m3/Hour

External Dimensions

220 x 180 x 360cm (mainbody)

Internal Dimensions

130 x 100 x 90cm(Primary Chamber)

Waste combustion chamber

1200Liters

Post Combustion Chamber

500Liters

Oil Tank Capacity

300 Liters

Door Opening

55 x 35cm

Chimney

10.0M

Gross Weight

4300kgs

Chamber Material

Firebrick ,Refractory Concrete

Max. Heat Value

250,000Kcal/Hr.

Operation Technical Specifications

Solid Chamber temperature

800⁰C -1000⁰C

Gas Chamber temperature

1000⁰C -1200⁰C

Chamber Anti-Rate

1450⁰C

Residency time

2.0 Sec.

Burning efficiency

＞98%

Waste Lower Calorific Power

3000Kcal
