Model

YZ-100

Capacity(Kgs/Hour)

About 100

Applicable Sick Bed(Beds)

1000

Voltage(V)

220

Power(Kw)

1.3

Oil

Diesel Oil(light Diesel oil beneath 10#)

Burner

Baltur, Italy Original

Feed Mode

Manual

Prohibit Waste

Incombustible and explosive materials not allowed in

Chamber thickness(Firebrick) (mm)

160

Steel Thickness(mm)

4

Gross Weight(Kgs)

4100

Package Material

Wooden Carton

Package Size(mm)

270 x 220 x 225

Chimney

Length: 6.4M, Diameter:350mm

Oil Tank Capacity(Kgs)

120

Fuel consumption:

Primary Burner: 7.5-14.5Kgs/Hour

Secondary Burner: 7.5-14.5Kgs/Hour

Solid combustion chamber((Primary& Secondary)

0.9M3

Gas Combustion Chamber

0.4M3

Solid Chamber temperature(⁰C)

800-1000

Gas Chamber temperature(⁰C)

1000-1200

Burning efficiency

＞98%
