Equipment Technical Specifications

Model

YD-300

Feed Capacity

600-1200 kgs per feed

Burning Rate

300 kgs per hour

Burning Time per Feed

2-4 hours

Voltage

380V

Power

1.48Kw

Fuel

Natural Gas or Diesel oil

Burner

Italy Burner

Feed Mode

Manual

Fuel consumption (Oil)

14.0-34.0 Kgs/Hour

Fuel consumption (Gas)

13.0-38.0m3/Hour

External Dimensions

260 x 220 x 420cm (mainbody)

Internal Dimensions

220 x 110 x 100cm(Primary Chamber)

Waste combustion chamber

2400Liters

Post Combustion Chamber

1200Liters

Oil Tank Capacity

500 Liters

Door Opening

90 x 110cm

Chimney

10.0M

Gross Weight

8300kgs

Chamber Material

Firebrick ,Refractory Concrete

Max. Heat Value

340,000Kcal/Hr.

Operation Technical Specifications

Solid Chamber temperature

800⁰C -1000⁰C

Gas Chamber temperature

1000⁰C -1200⁰C

Chamber Anti-Rate

1450⁰C

Residency time

2.0 Sec.

Burning efficiency

＞98%

Waste Lower Calorific Power

3000Kcal
