 Containerized Mobile Incinerator New

 Incinerator Project Case

☆Incinerator YD-30 for Australia

☆Incinerator YD-50 for Moldova

☆Incinerator YD-100 for Iraq

☆Incinerator YD-150 for Morocco

☆Incinerator YD-300 for Somalia

☆Incinerator YD-500 for Vietnam

 Medical Waste Incinerators

☆30kgs per hour&Model YD-30

☆50kgs per hour&Model YD-50

☆100kgs per hour&Model YD-100

☆150kgs per hour&Model YD-150

☆300kgs per hour&Model YD-300

☆500kgs per hour&Model YD-500
　

Incinerator Project Case

1. Burning Rate 50-120kg/hr -- 50kg per hour

2. minimum operating temp 850degrees cel (primary combustion)-- 800-1000 °ϲ

3. Max operating temp 1450 degrees cel (afterburner chamber)-- 1000-1200°ϲ

4. Secondary Burning capacity compulsory—yes

5. Density Insulation 20mm high—50mm

6. Refractory casting Minimum 65mm—200mm,chimney for incinerator capacity 50 kgs per hour, biological incinerators

7. Heavy duty refracting lining to withstand 1500 degrees cel.-- 1700°ϲ

8. Average burn out time: maximum 3.0 hrs—1 hour

9. Fuel Type Diesel--diesel oil

10. Fuel Consumption in L/hr --12.1-24kg/hour

11. Residence time in secondary chamber 2 sec—2.0 sec.

12. Residue ash post 100kg max. 3.8kg --- 2.0kg

13. Installation period maximum 7 days –2-3 days
