CLOVER Incinerator
Call us on 0086-25-8461 0201
[email protected]
China Medical Incinerators /
Animal Cremation / Waste Incinerators
|
Items/Model |
YD-10C |
YD-20C |
YD-30C |
YD-50C |
|
Burning Rate (kgs/Hour) |
10 kgs/Hr. |
20 kgs/Hr. |
30 kgs/Hr. |
50 kgs/Hr. |
|
Feed Capacity (kgs) |
40 kgs |
40 kgs |
50 kgs |
80 kgs |
|
Equipment Weight |
2100 kgs |
2100 kgs |
2300 kgs |
2500 kgs |
|
Primary Chamber (Liters) |
200 |
200 |
250 |
400 |
|
Secondary Chamber (Liters) |
140 |
140 |
140 |
140 |
|
External Dimensions (cm) |
170x140x160 |
170x140x160 |
170x140x190 |
180x160x200 |
|
Internal Dimensions (cm) |
55x55x65 |
55x55x65 |
55x55x85 |
70x70x85 |
|
Oil Tank(Liters) |
50 |
100 |
100 |
150 |
|
Door Opening (cm) |
38 x 48 |
38 x 48 |
38 x 48 |
45x55 |
|
Chimney (M) |
5 |
5 |
5 |
5 |
|
Chimney Type |
Stainless Steel |
Stainless Steel |
Stainless Steel |
Stainless Steel |
|
Secondary Chamber |
YES |
YES |
YES |
YES |
|
Mix-Combustion Chamber |
YES |
YES |
YES |
YES |
|
Smoke Filter Chamber |
YES |
YES |
YES |
YES |
|
Combustion Fuel |
Oil/Gas |
Oil/Gas |
Oil/Gas |
Oil/Gas |
|
Residency Time |
2.0 Sec. |
2.0 Sec. |
2.0 Sec. |
2.0 Sec. |
|
Temperature Monitoring |
YES |
YES |
YES |
YES |
|
1st. Chamber Temperature |
800℃--1000℃ |
800℃--1000℃ |
800℃--1000℃ |
800℃--1000℃ |
|
2nd. Chamber Temperature |
1000℃-1200℃ |
1000℃-1200℃ |
1000℃-1200℃ |
1000℃-1200℃ |
|
|
|
