CLOVER Incinerator

Call us on  0086-25-8461 0201  [email protected]

China Medical Incinerators /  Animal Cremation / Waste Incinerators

The past few months have been a very busy time for CLOVER. The outbreak of Ebola in West Africa has resulted in all of the Global aid organisations contacting CLOVER to support them in getting the necessary equipment to the effected regions.
containment

The United Nations, UNOPS and local agents are now in constant contact with CLOVER in their attempts to stop the potential of further contamination by destroying medical waste streams at the source.

Regular model incinerator for market with burning rate from 10kgs to 500kgs per hour and we always proposal customer send us their require details, like waste material, local site fuel and power supply, incinerator operation time, etc, so we can proposal right model or custom made with different structure or dimensions. CLOVER have a wide range of medical Incinerators that allow for small batches of 10kg up to an impressive 600kg per hour. Many years of research and development has made CLOVER a company that is globally renowned and respected and are the go to company for a diverse set of organisations when such problems arise. The quality of our China manufactured product is of the highest standard and the warranties reflect the performance and life cycle of our Incinerators. All of the organisations have shown great interest in the Innovative and high performing mobile model that gives both performance and mobility, we currently have a large number of this model on route to the region as we speak.

incinerator-for-ebola

We are now talking to the individual countries about their ongoing requirements to support the process of this virus being contained and eventually eradicated. Our range of mobile incinerators are the ideal solution to enable mobile and instant waste management to areas that are restricted due to infrastructure and remoteness.

CLOVER will continue to strive on many fronts to ensure that our product range is the best in the Incinerator market and part of that process is the ability to service markets and disaster areas in the quickest possible time. This we will do with the utmost priority in servicing all of the Aid organisations and government agencies to win the battle against Ebola.

We urge everyone who can assist to do their utmost to help and support the people of West Africa, in the belief of bringing this problem to an end, Join us on our Social Media platforms to support the Ebola effort.

Equipment Technical Specifications

Model

YD-10C

Feed Capacity

40-80 kgs per feed

Burning Rate

10 kgs per hour

Burning Time per Feed

3.0 -5.0hours

Voltage

220V

Power

0.50Kw

Fuel

Natural Gas or Diesel oil

Burner

Italy Burner

Feed Mode

Manual

Fuel consumption (Oil)

4.4-9.4 Kgs/Hour

Fuel consumption (Gas)

5.3-11.2m3/Hour

External Dimensions

170 x 140 x 160cm (mainbody)

Internal Dimensions

55 x 55 x 65cm(Primary Chamber)

Waste combustion chamber

200Liters

Post Combustion Chamber

140Liters

Oil Tank Capacity

50 Liters

Door Opening

38 x 48cm

Chimney

5.0M

Gross Weight

1200kgs

Chamber Material

Refractory Concrete

Max. Heat Value

94,000Kcal/Hr.

Operation Technical Specifications

Solid Chamber temperature

8000C -10000C

Gas Chamber temperature

10000C -12000C

Chamber Anti-Rate

13500C

Residency time

2.0 Sec.

Burning efficiency

£¾98%

Waste Lower Calorific Power

3000Kcal

¡¡

¡¡

¡¡ ¡¡
