China Medical Incinerators /
Animal Cremation / Waste Incinerators
|
Equipment Technical Specifications |
|
Model |
YD-20C |
|
Feed
Capacity |
40-80
kgs per feed |
|
Burning
Rate |
20 kgs
per hour |
|
Burning
Time per Feed |
2.0-4.0
hours |
|
Voltage |
220V |
|
Power |
0.50Kw |
|
Fuel |
Natural Gas or Diesel oil |
|
Burner |
Italy
Burner |
|
Feed
Mode |
Manual |
|
Fuel
consumption (Oil) |
5.4-12.6
Kgs/Hour |
|
Fuel
consumption (Gas) |
6.5-15.0m3/Hour |
|
External
Dimensions |
170 x
140 x 160cm (mainbody) |
|
Internal
Dimensions |
55 x 55
x 65cm(Primary Chamber) |
|
Waste
combustion chamber |
200Liters |
|
Post
Combustion Chamber |
140Liters |
|
Oil Tank
Capacity |
100
Liters |
|
Door
Opening |
38 x
48cm |
|
Chimney |
5.0M |
|
Gross
Weight |
1200kgs |
|
Chamber
Material |
Refractory Concrete |
|
Max.
Heat Value |
126,000Kcal/Hr. |
|
Operation Technical Specifications |
|
Solid
Chamber temperature |
8000C
-10000C |
|
Gas
Chamber temperature |
10000C
-12000C |
Chamber Anti-Rate
|
13500C |
Residency time
|
2.0
Sec. |
|
Burning efficiency |
＞98% |
|
Waste
Lower Calorific Power |
3000Kcal |
|
|
|
