Email: [email protected] Tel: +8625-8461 0201
A model pet animal crematory include A360, A900, A1200, A1500, A2400, A4000. All models with double combustion chamber and big combustion chamber. Burn rate is 20/30/60//90/150/250kgs per hour for animal/pet.
 |
 |
 |
|
Equipment Technical Specifications |
|||||
|
Model |
A900 | A1200 | A1500 | A2400 | A4000 |
|
Feed Capacity (kgs/feed) |
50-90 | 80-120 | 100-150 | 200-240 | 300-400 |
|
Burning Rate (Kgs/Hour) |
30 | 60 | 90 | 150 | 250 |
|
Voltage |
380V | ||||
|
Power (Kw) |
0.7 | 0.9 | 1.03 | 1.48 | 2.24 |
|
Fuel |
Natural Gas or Diesel oil | ||||
|
Burner |
Italy Burner | ||||
|
Feed Mode |
Manual | ||||
|
Fuel consumption (Oil, Kgs/Hour) |
8.0-20.0 | 12.0-25.0 | 14.0-30.0 | 14.0-34.0 | 22.0-40.0 |
|
Fuel consumption (Gas, M3/Hour) |
10.0-20.0 | 12.0-30.0 | 13.0-35.0 | 13.0-38.0 | 20.0-45.0 |
|
Waste combustion chamber (Liters) |
900 | 1000 | 1500 | 2400 | 4000 |
|
Post Combustion Chamber (Liters) |
300 | 500 | 500 | 1200 | 1500 |
|
Chimney |
5.0M | 10.0M | 10.0M | 10.0M | 14.0M |
|
Gross Weight |
4000Kgs | 4300Kgs | 7000Kgs | 8300Kgs | 13000Kgs |
|
Chamber Material |
Firebrick ,Refractory Concrete | ||||
|
Max. Heat Value (Kcal/Hr.) |
200,000 | 250,000 | 300,000 | 340,000 | 400,000 |
|
Operation Technical Specifications |
|||||
|
Solid Chamber temperature |
800 0C -1000 0C |
||||
|
Gas Chamber temperature |
1000 0C -1200 0C |
||||
Chamber Anti-Rate
|
14500C |
||||
Residency time
|
2.0 Sec. |
||||
|
Burning efficiency |
＞98% |
||||
|
|
