Description

Riello FS20 Gas burner One stage operation MVDLE2075 with automatic Flame Thermal Adjust function

569T30

Thermal power (1) 81 – 220 kW – 70,000 – 189,000 kcal/h

Natural gas (Family 2)

Net heat value: 8 – 12 kWh/Nm3 – 7,000 – 10,340 kcal/Nm3

Pressure: min. 20 mbar – max. 100 mbar

Electrical supply Single phase, 230V ± 10% ~ 50Hz

Motor 230V / 1.4A

Capacitor 5 μF

Ignition transformer Primary 230V / 1.8A – Secondary 8 kV / 30 mA

Absorbed electrical power 0.25 kW

(1) Reference conditions: Temp. 20°C – Barometric pressure 1013 mbar – Altitude 0 m above sea level.
