Burning ability 50kg/hr with damp scrubber with dual released heater

This model is small-scale waste incineration equipment for small waste output.
Construction is dual/double combustion chamber with 02 units oil/gas burner.
Waste feed chamber is around 900Liters (0.9m3, YD-50). Primary & Secondary
combustion chambers and included mix-combustion chamber. Waste load on the
bottom of chamber. Incinerator panel control suit for local operation.

Design

YD-50 with wet scrubber


Burning Cost

Ordinary 50 kgs/hour

Feed Ability

Average 100 kgs

Main Combustion Chamber

900 Liters

Secondary Burning Chamber

200 Litres

Mix Burning Chamber

Yes

Smoke Filter Chamber

Damp Scrubber( Laundering Tower)

Feed Establishing

Guide

Voltage

220V

Power

7 Kw

Gas Kind

Diesel Oil/ All-natural Gas/LPG

Heater

Italy Original

Oil Use (Diesel Oil)

16.9 kg/hour

Gas Consumption (Gas)

***

Internal Measurements

120x90x85cm (vital chamber)

Outside Measurements

400x200x230cm (without smokeshaft)

Temperature Level Degree Screen

Yes

Oil Container Ability( if petroleum gasoline )

300 Litres

Door Opening

62 x 68cm

Chimney Size

5.0 Meters

Smokeshaft Type

Stainless Steel

Equipment Gross Weight

6000 kgs

Remedy Technical Specifications

Main Chamber Temperature

800 ℃–– – – -1000 ℃

Extra Chamber Temperature

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Burning Efficiency

> 98%

Waste Lower Calorific Power

3000Kcal
