the china incinerators with reasonable price for customer and good quality for long time use. We […]
Capacity Not less than 500Kg/hr.Operation 24hr-7days/week continuous operation.Combustion chamber 2 combustion chamber.Temp. First combustion chamber 800-1000 C. Secandry combustion chamber 1000-1200 C, with the possibility to be upgraded to 1400 C.Combustion Efficiency 99.99%Retention time Of the flow gases not less than 2 Sec in the hot portion.Excess Oxygen concentration Of primary combustion chamber 3-6% max. Refractory The chambers should be lined with high thermal insulating refractory bricks with suitable thickness and with highly temp. resistance. Not less than 1400 C for the first combustion chamber, and not less than 1600 C for the secandry combustion chamber, and at the same time prevent the Temp. of the outside body of the chamber not higher than 70 C.Doors Should be lined with the same bricks, and the edges lined with special suitable insulating material to prevent any gas escaping, and the doors should be kept under negative pressure during the operation.Air Emission Control System With high destruction and removal efficiency (DRE). Not less than 99.9999 as per KEPA.Wet System If the system equiped with a CEMS washing the flow gas with water, then it should be manufactured from suitable anti corrossion materials, and equiped with pH meter to measure and neutralize the water. It should be able to use the water in closed recycled circuit many times before treating/ discharging into the sewage system in compliance with KEPARS.Chemical dosing It should be equiped with suitable autochemical dosing system to control the pH for the water of the wet scrubber system including sensors.Chimney It should be suitable with the capacity and the technical specifications, with height not less than 12m from ground level. With easy opennable sampling point equal about 3 inch, and the optimum sampling locations is at least 8D downstream direction and 2D upstream from any flow disturbancies.Sampling point […]
We supply single combustion chamber, double combustion chambers, three combustion chambers and multi-combustion chambers waste incinerators […]
we are famous brand(Hiclover) china incinerator manufacturer and all over the world. We supply single combustion […]
We supply single combustion chamber, double combustion chambers, three combustion chambers and multi-combustion chambers waste incinerators […]
incinerator china, call hiclover brand(www.hiclover.com). Nanjing Clover Medical Technology Co.,Ltd. is top incinerator supplier in china […]
We supply single combustion chamber, double combustion chambers, three combustion chambers and multi-combustion chambers waste incinerators […]
incinerators for solid waste, medical waste, animal wate incineration or cremation. We supply single combustion chamber, […]
HICLOVER, Nanjing Clover Medical Technology Co.,Ltd, supply system solutions for medical environmental protection, animal and pet […]
* Burning Rate (50-120kg/hour)* Minimum Operating Temperature (850°ϲ(Primary combustion)* Maximum Operating Temperature (1450°ϲ(Afterburner chamber)* Secondary Burning Capacity (Compulsory)* Density Insulation (20mm high)* Refractory Casting (Minimum 65mm)* Heavy duty refracting lining to withstand (1500°ϲ)* Average burn out time: Maximum (3.0 hours)* Fuel Type (Diesel)* Fuel Consumption in L/hr: (7.5 to 9)* Residence time in secondary chamber (2 sec.)* Residue ash post 100kg (Max. 3.8kg)* Installation period (Maximum 7days)Type : Refractory constructionsSteel Structure 400+ Silica board + Fire Brick andCastable betweenSize : Outside – W 740 x L 1112 x H 790 / Inside – W 400 x L 800 x H 560 (mm)Fire load of Combustion volume : 0.18 m3Fire table area : 0.32 m2Material : SS400 x 6.0T, Silica Board, Fire Brick (SK-36), Castable (HACT-160)Temperature : 700 ~ 900 ℃Residual gas combustion in secondary chambers : ≥ 2secInput door size : W 200 x H 200 (mm)Ash door size : W 300 x H 400 (mm)Type : Refractory constructionsSteel Structure 400+ Silica board + Fire Brick and Castable betweenSize : Outside – W 740 x L 1112 x H 745 / Inside – W 400 x L 800 x H 600 (mm) Fire load of Combustion volume : 0.19 m3 Fire table area : 0.32 m2Material : SS400 x 6.0T, Silica Board 50T, Fire Brick (SK-36), Castable (HACT-160) Temperature : 1000 ~ 1100 ℃ WWW.HICLOVER.COM｜Waste Incinerators ｜Auto Roll Air Filters Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-25-8461 0201 Mobile: +86-13813931455(whatsapp/wechat)Website: www.hiclover.com Email: [email protected]Email: [email protected] Items/Model TS10(PLC) TS20(PLC) TS30(PLC) […]
