Animal Crematory Incinerator Model A600

Item	Specification
Model	A600
Internal Dimensions	130 x 70 x 65cm
Suit for Animal	Cat – yes	Dog – yes	Pig – no	Cow – no
Main Product List	Primary Combustion Chamber
	Secondary Combustion Chamber
	Mix-Combustion Chamber
	Smoke Filter Chamber
	Incinerator Control Case
	Chimney:5.0Meters *(upgrade to Stainless Steel, free cost)
	Italy oil/gas burner: 02 units
	Oil Tank (if oil fuel): 200Liters

WWW.HICLOVER.COM｜Waste Incinerators ｜Auto Roll Air Filters

Nanjing Clover Medical Technology Co.,Ltd.

Tel:  +86-25-8461 0201

Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]

Model	A600
Feed Capacity	Average 30 kgs per feed(animal)
Burning Rate	Average 10 kgs per hour(animal)
Voltage	220V
Power	0.59Kw
Fuel	Natural Gas or Diesel oil
Burner	Italy Burner
Feed Mode	Manual
Fuel consumption (Oil)	10.0-16.0 Kgs/Hour
Fuel consumption (Gas)	10.0-15.0m3/Hour
External Dimensions	175 x 100 x 180cm (main body)
Internal Dimensions	130 x 70 x 65cm(Primary Chamber)
Waste combustion chamber	600Liters
Post Combustion Chamber	200Liters
Oil Tank Capacity	200 Liters
Door Opening	50 x 60cm
Chimney	5.0M
Gross Weight	3300kgs
Chamber Material	Refractory Concrete
Max. Heat Value	160,000Kcal/Hr.
Operation Technical Specifications
Solid Chamber temperature	8000C -10000C
Gas Chamber temperature	10000C -12000C
Chamber Anti-Rate	14500C
Residency time	2.0 Sec.
Burning efficiency	＞98%
Waste Lower Calorific Power	3000Kcal
