Medical Waste Incinerator YD Model is our classic product for market. All
series included burning capacity 10kgs per hour, 30kgs per hour,50kgs per
hour,100kgs per hour,150kgs per hour,300kgs per hour,500kgs per hour. Up to now,
all models sale to all over the world and have good feedback from end-customer.
The YD Model medical incinerator have multi-combustion chamber and basic dry
scrubber (smoke filter chamber) with reasonable project budget. For the
cleaner emission require, we accept custom made wet scrubber for incinerator and
this will be also our next working by focusing on emission technical.
Regular model incinerator for market with burning rate from 10kgs to 500kgs
per hour and we always proposal customer send us their require details, like
waste material, local site fuel and power supply, incinerator operation time,
etc, so we can proposal right model or custom made with different
structure or dimensions.
incinarators in
peru hospitals, incinerator manufacturers, incenerateur, incinerator
Now, please download "Product
Request Form (Word Format, 51KB)", complete and send back to us. Email:
[email protected]
Incinerator Model YD-100 is a middle scale incineration machine for many
different usage: for a middle hospital sickbed below 500 units, for all
small or big size family pets (like Alaskan Malamute Dog), for community
Municipal Solid Waste Incineration, etc. The primary combustion chamber volume
is 1200Liters (1.2m3) and use diesel oil or natural gas fuel burner original
from Italy.
All our incinerator use stainless steel chimney, not steel.
All our incinerator have two combustion chamber at least, not single
chamber.
All fuel burner from Italy made with famous brand, best quality.
300kgs per hour burning rate incinerator is well liked by market
because this model can be medical waste incineration equipment for big hospital
and also very good for other solid waste treatment with lowest cost, even if big
size animals also can be feed into the combustion chamber. The primary
combustion chamber volume is 2.4m3, big enough for common size animals. For
shipping transport, YD-300 can be loaded into 40'feet full high container.
Big size combustion chamber up to 4.0m3 and Internal Dimensions is 257 x
147 x 108cm with feeding door opening 108 x 128cm. This model can be a small
waste incineration factory with little amount of budget funds. If end customer
use this for farm to burn animals like cow, horse or camel, no problem!
An Incinerator is to be supplied by
the Contractor on a rental basis at a location established by the Company. The
Contractor is to provide trained and competent personnel with initial
installation, commissioning and operational training under the supervision of
the manufacturer��s technician. The incinerator is to be maintained and operated
to manufacturer��s specifications by trained personnel. Contractor must have
sufficient personnel trained and competent to operate the incinerator throughout
the contract period. Specifications for the incinerator are attached in Appendix
A.
Incinerator Use/Ash Collection
Incinerators used will be limited
to daylight hours of operation. This includes shutdown, cleaning and
maintenance.
Waste streams shall not be mixed
during the incineration process and the ash collection chamber will be cleaned
when a different waste stream is to be incinerated. The Company will provide the
contractor with a list of items that can be incinerated.
All ash will be collected and
stored in individual storage bins for each particular waste stream. The bins are
to be provided by the contractor to the same design as the storage bins for the
raw waste streams and include a lid design that prevents contamination from
water.
Ash from each waste stream will be
sent for laboratory analysis after each initial incineration by the Company and
at intervals decided by the Company thereafter. Contractor will be required to
collect ash samples for analysis as directed by the Company. The Contractor will
be responsible for the security of samples taken to prevent contamination until
collection by the Company or designated courier.
Ash will be disposed of at the
direction of the Company. It is the responsibility of the Contractor to ensure
the ash is not compromised until final disposal. Company will provide additional
storage area for ash if and as required.
��
��
��
��
��
��
��
��
��
��
��
��
��
��
�� |
