CLOVER Incinerator
Call us on 0086-25-8461 0201
[email protected]
China Medical Incinerators /
Animal Cremation / Waste Incinerators
 |
|
Items/Model |
YD-30 |
YD-50 |
YD-100 |
YD-150 |
|
Burning Rate (kgs/Hour) |
30 kgs/Hr. |
50 kgs/Hr. |
100 kgs/Hr. |
150 kgs/Hr. |
|
Feed Capacity (kgs) |
60 kgs |
150 kgs |
200 kgs |
300 kgs |
|
Equipment Weight |
2300 kgs |
4000 kgs |
5300 kgs |
7000 kgs |
|
Primary Chamber (Liters) |
360 |
900 |
1200 |
1500 |
|
Secondary Chamber (Liters) |
200 |
200 |
500 |
500 |
|
External Dimensions (cm) |
145x90x175 |
200x160x230 |
220x180x360 |
240x170x380 |
|
Internal Dimensions (cm) |
100x60x60 |
120x90x85 |
130x100x90 |
150x100x96 |
|
Oil Tank(Liters) |
200 |
300 |
300 |
300 |
|
Door Opening (cm) |
48 x 60 |
62 x 80 |
55 x 80 |
59 x 81 |
|
Chimney (M) |
5 |
5 |
10 |
10 |
|
Chimney Type |
Stainless Steel |
Stainless Steel |
Stainless Steel |
Stainless Steel |
|
Secondary Chamber |
YES |
YES |
YES |
YES |
|
Mix-Combustion Chamber |
YES |
YES |
YES |
YES |
|
Smoke Filter Chamber |
YES |
YES |
YES |
YES |
|
Combustion Fuel |
Oil/Gas |
Oil/Gas |
Oil/Gas |
Oil/Gas |
|
Residency Time |
2.0 Sec. |
2.0 Sec. |
2.0 Sec. |
2.0 Sec. |
|
Temperature Monitoring |
YES |
YES |
YES |
YES |
|
1st. Chmaber Temperature |
800¡æ--1000¡æ |
800¡æ--1000¡æ |
800¡æ--1000¡æ |
800¡æ--1000¡æ |
|
2nd. Chmaber Temperature |
1000¡æ-1200¡æ |
1000¡æ-1200¡æ |
1000¡æ-1200¡æ |
1000¡æ-1200¡æ |
¡¡
|
Items/Model |
YD-200 |
YD-300 |
YD-500 |
YD-600 |
|
Burning Rate (kgs/Hour) |
200 kgs/Hr. |
300 kgs/Hr. |
500 kgs/Hr. |
600 kgs/Hr. |
|
Feed Capacity (kgs) |
400 kgs |
500 kgs |
800 kgs |
1100 kgs |
|
Equipment Weight |
7600 kgs |
8300 kgs |
13000 kgs |
16500 kgs |
|
Primary Chamber (Liters) |
2000 |
2400 |
4000 |
5500 |
|
Secondary Chamber (Liters) |
500 |
1200 |
1500 |
1500 |
|
External Dimensions (cm) |
270 x 185 x 380 |
260x220x420 |
320x220x460 |
360 x 220 x 475 |
|
Internal Dimensions (cm) |
180 x 115 x 96 |
220x110x100 |
257x147x108 |
300 x 147 x 125 |
|
Oil Tank(Liters) |
300 |
500 |
500 |
500 |
|
Door Opening (cm) |
59 x 81 |
90 x 110 |
108 x 128 |
108 x 128 |
|
Chimney (M) |
10 |
10 |
14 |
14 |
|
Chimney Type |
Stainless Steel |
Stainless Steel |
Stainless Steel |
Stainless Steel |
|
Secondary Chamber |
YES |
YES |
YES |
YES |
|
Mix-Combustion Chamber |
YES |
YES |
YES |
YES |
|
Smoke Filter Chamber |
YES |
YES |
YES |
YES |
|
Combustion Fuel |
Oil/Gas |
Oil/Gas |
Oil/Gas |
Oil/Gas |
|
Residency Time |
2.0 Sec. |
2.0 Sec. |
2.0 Sec. |
2.0 Sec. |
|
Temperature Monitoring |
YES |
YES |
YES |
YES |
|
1st. Chmaber Temperature |
800¡æ--1000¡æ |
800¡æ--1000¡æ |
800¡æ--1000¡æ |
800¡æ--1000¡æ |
|
2nd. Chmaber Temperature |
1000¡æ-1200¡æ |
1000¡æ-1200¡æ |
1000¡æ-1200¡æ |
1000¡æ-1200¡æ |
The required
circular Medical Waste Incinerator will
be quoted in accordance with Technical
Specifications provided below:
1) A self-contained, diesel fuel,
medical waste incinerator with a minimum
burn rate capacity of 100 kg/day.
2) A medical waste incinerator shall be
specifically designed by the
manufacturer to dispose of all
Bio-Hazard medical wastes.
3) At a minimum the unit shall be sized
to incinerate 2.0 kg/exam-room/24-hrs
when being operated continuously for 12
hours per day, but no less than
100kg/day total.
4) The Incinerator shall be manually
batch fed.
5) The incinerator fuel tank shall meet
the following requirements:
a) The tank shall be installed above
ground and according to all of the fuel
tank requirements in Section 1015
including secondary containment.
b) The tank shall be sized to hold a 14
day supply of diesel fuel
6) Manufacturer has to provide the
following capacity calculations and all
supporting information for the
incinerator:
The daily waste stream rate (kg/day or
lbs/day)
Minimum incinerator burn rate capacities
Minimum cure time for the refractory to
prevent cracking to the refractory
A complete list of the maintenance parts
A minimum of 500 lbs of refractory for
repairs
A minimum of 1 gallon of hydraulic oil
¡¡
¡¡ |
¡¡ |
¡¡ |
